1.3 Icons used
Menu icons
Menu Icon
Main screen
Machine Settings
Aux. Equipment Parameters
Data
Service
Controller Settings
Information
Status icons
Icon Description
Motor Stopped
Motor Stopped Wait
Running Unloaded
Manual Unload
Running Unloaded Wait
Running Loaded
Running Loaded Wait
Machine Control Mode, Local
Instruction book
