Electrical diagram
2205 0147 00 Service diagram G 15L – G 18 – G 22 IEC
2205 0324 00 Service diagram G 15L – G 18 – G 22 cULus/ cCSAus
The complete electrical diagram can be found in the electric cubicle.
The complete electrical diagram can be found on the USB supplied with the machine.
2.8 Protection of the compressor
Safety valve on the compressor and on the vessel
Reference Designation Function
SV Safety valve To protect the air outlet system if the outlet pressure
exceeds the opening pressure of the valve.
Instruction book
22 2920 7119 21
