3.3 Icons used on the display
Function Icon Description
Stopped/Running When the compressor is stopped, the icon stands still.
When the compressor is running, the icon is rotating.
Compressor status Motor stopped
Running unloaded
Running unloaded (blinking for manual stop)
Only for 5.5 - 7.5 kW (7.5 - 10 HP) units.
Running loaded
Machine control mode Remote start/stop active
Automatic restart after
voltage failure
Automatic restart after voltage failure is active
Active protection functions Emergency stop
Service Service required
Instruction book
30 2920 7199 10
