Atlas Copco G 2

Overview of the screens
Menu item Submenu Digital input screen Designation
<dAtA>
(Data)
<d.1> Running hours.
<d.2> Motor starts.
<d.3> Module hours.
<d.4> Loading hours.
<d.5> Load solenoid valve.
Only for 5.5 - 7.5 kW (7.5 - 10 HP) units.
<d.6> Service timer.
<ProG>
(Programming)
<rEG.P>
(Regulation
Pressure)
<Pr.SL> Calling up or modifying pressure band
selection.
<LPr.1> Calling up or modifying lower pressure
setting.
<uPr.1> Calling up or modifying upper pressure
setting.
<LPr.2> Calling up or modifying lower pressure
setting.
<uPr.2> Calling up or modifying upper pressure
setting.
<tiMr>
Timer
<SrV.d> Maintenance warning.
<diSP>
(Display)
<tEMP> Calling up or modifying unit of temperature.
<PrES> Calling up or modifying unit of pressure.
<bC.LG> Calling up or modifying time of backlight.
<Ctrl>
(Control)
<Lo.rE> Local/remote start/stop.
<Ar.Af> Automatic restart after voltage failure.
<Ar.d> Delay time of automatic restart after voltage
failure.
<nHCA> Maximum number of compressor starts per
hour.
Only for 5.5 - 7.5 kW (7.5 - 10 HP) units.
<PASS> Activating password protection.
<tESt>
(Test)
<tSt.1> Display test.
<InFo>
(Info)
<P.rEL> Parameter map release.
<F.rRl> Firmware release.
<F.dAY> Firmware release day.
<F.Mnt> Firmware release month.
<F.YAr> Firmware release year.
<SEr.n> Serial number.
3.10 Calling up running hours
