66
Instruction book
9096 3321 00
Minimum
setting
Factory
setting
Maximu
m setting
Unloading pressure bar(e) 4.1 6.9 7.4
Unloading pressure bar(e) 4.1 8.6 9.1
Unloading pressure bar(e) 4.1 10.3 10.8
Unloading pressure bar(e) 4.1 12 12.5
Loading pressures
Loading pressure (7.5 bar compressors) bar(e) 4 6.4 7.4
Loading pressure (8 bar compressors) bar(e) 4 6.9 7.9
Loading pressure (10 bar compressors) bar(e) 4 8.9 9.9
Loading pressure (13 bar compressors) bar(e) 4 11.9 12.9
Loading pressure bar(e) 4 6.3 7.3
Loading pressure bar(e) 4 8 9
Loading pressure bar(e) 4 9.7 10.7
Loading pressure bar(e) 4 11.4 12.4
Parameters: unloading/loading pressures for compressors with built-in refrigeration dryer
Minimum
setting
Factory
setting
Maximu
m setting
Unloading pressures
Unloading pressure (7.5 bar compressors) bar(e) 4.1 7 7.3
Unloading pressure (8 bar compressors) bar(e) 4.1 7.5 7.7
Unloading pressure (10 bar compressors) bar(e) 4.1 9.5 9.7
Unloading pressure (13 bar compressors) bar(e) 4.1 12.5 12.7
Unloading pressure (100 psi compressors) bar(e) 4.1 6.9 7.1
Unloading pressure bar(e) 4.1 8.6 8.8
Unloading pressure bar(e) 4.1 10.3 10.5
Unloading pressure bar(e) 4.1 12 12.2
Loading pressures
Loading pressure (7.5 bar compressors) bar(e) 4 6.4 7.2
Loading pressure (8 bar compressors) bar(e) 4 6.9 7.6
Loading pressure (10 bar compressors) bar(e) 4 8.9 9.6
Loading pressure (13 bar compressors) bar(e) 4 11.9 12.6
Loading pressure bar(e) 4 6.3 7
Loading pressure bar(e) 4 8 8.7
Loading pressure bar(e) 4 9.7 10.4
Loading pressure bar(e) 4 11.4 12.1
