Industrial Air Division Instruction book
AR. Air receiver/oil separator
AV. Air outlet valve
Ca. Air cooler
Co. Oil cooler
CV. Check valve
E. Compressor element
E1. Elektronikon control
module
FC. Oil filler plug
FN. Fan, compressor coolers
Gl. Oil level gauge
M1. Compressor motor
M2. Fan motor
OF. Oil filter
S0. Isolator switch
SV. Safety valve
VP. Venting plug, oil cooler
1. Cooler plate
2. Flexible, oil drain
3. Arrow, rotation direction
of fan motor
Figs. 3. Front views
Fig. 3b. Front view of GA90 VSD
Fig. 3a. Front view of GA50 VSD
Ca E1
AV
SO
M1
F002
E
CV
OF
FN
1
CO
