- 69 -
Rated power factor (lagging) 3-phase 0.8
Rated power factor (lagging) 1-phase - 1.0
Rated apparent power (PRP) 3-phase 12.5 kVA -
Rated apparent power (PRP) 1-phase - 10.9 kVA
Rated voltage 3-phase, line to line 400 V -
Rated voltage 1-phase, line to line - 230 V
Rated current 3-phase 18 A -
Rated current 1-phase - 47.6 A
Performance class (acc.ISO 8528-5:1993) G2 G2
Single step load acceptance (0-PRP) 10.0 kW 10.9 kW
100% 100%
Frequency droop < 5% < 5%
Fuel consumption at no load (0%) 0.76 kg/h 0.76 kg/h
Fuel consumption at 50% load 1.54 kg/h 1.54 kg/h
Fuel consumption at 75% load 2.11 kg/h 2.11 kg/h
Fuel consumption at full load (100%) 2.63 kg/h 2.63 kg/h
Specific fuel consumption 0.285 kg/kWh 0.295 kg/kWh
Fuel autonomy at full load 12.6 h 11.5 h
Max. oil consumption at full load 0.0089 l/h 0.0097 l/h
Maximum sound power level (LWA) measured according to 2000/14/EC OND
with metal canopy 91 dB(A) 91 dB(A)
with PE canopy (optional) 89 dB(A) 89 dB(A)
Capacity of fuel tank 40 l 40 l
Single step load capability (0-PRP) 10.0 kW 10.9 kW
100% 100%
Application data Mode of operation PRP PRP
Site land use land use
Operation single single
Start-up and control mode manual/automatic
(remote)
manual/automatic
(remote)
Start-up time unspecified unspecified
Mobility/Config. acc. to ISO 8528-1:1993 transportable/D transportable/D
(optional) mobile/E mobile/E
