Atlas Copco XAHS 146 Dd S3B APP User Manual

- 26 -
CIRCUIT DIAGRAM 9822 0893 16
XAHS 186, XAVS 166
Tag Desc. 1 Desc. 2 Location Sheet/
Col.
B1 Temperature sensor Compressor element
temperature
Machine 04/2
D1 Diode Machine 03/9
F2 Fuse Mains 30A Power box 02/2
G1 Battery Power Machine 02/1
G3 Alternator Charging Engine 02/3
K0 Relay Starter motor Engine 02/2
LS1 Level switch Coolant level Machine 04/5
LT1 Level sensor Fuel level Machine 04/6
M1 Motor Starter Engine 02/2
PT1 Pressure sensor Regulating pressure Machine 04/1
PT2 Pressure sensor DPF ΔP Machine 03/1
Q1 Circuit breaker 15A Controller Power box 02/4
R4 Resistor 120 Ohm Machine 02/10
R5 Resistor 120 Ohm Machine 02/10
R6 Resistor 120 Ohm Machine 03/4
R7 Resistor 47 Ohm Machine 03/9
R8 Resistor 120 Ohm Machine 03/4
R9 Resistor 120 Ohm Machine 04/2
S1 Switch Battery cut-off Customer 04/6
S4 Switch Water in fuel level Machine 02/5
S5 Switch Remote emergency stop Customer 04/9
TT2 Temperature sensor Air intake DPF Machine 02/5
TT3 Temperature sensor Before OXY Machine 03/1
TT4 Temperature sensor After OXY Machine 03/1
Tag Desc. 1 Desc. 2 Location Sheet/
Col.
X1 Connector Control panel Machine 04/2
X2.1 Connector D2.1 Machine 03/3
X2.1 Connector D2.2 Machine 02/4
X17.1 Connector Interface Engine 03/1
X17.2 Connector Interface Engine 03/1
X10 Connector Cosmos control panel Machine 04/3
X11 Connector Cosmos Optional 04/3
X22 Connector Diagnostic Machine 02/10
Y1 Solenoid valve Load Machine 04/9
Wire size Colour code
aa = 0.75 mm
2
0 = black
a = 1 mm
2
1 = brown
b = 1.5 mm
2
2 = red
bx = 1.5 mm
2
NSGAFOÜ 3 = orange
c = 2.5 mm
2
4 = yellow
cx = 2.5 mm
2
NSGAFOÜ 5 = green
d = 4 mm
2
6 = blue
e = 6 mm
2
7 = purple
f = 10 mm
2
8 = grey
fx = 10 mm
2
NSGAFOÜ 9 = white
h = 25 mm
2
54 = green/yellow
l = 95 mm
2
mx = 120 mm
2
EPR-CSP to BS6195 4C
nx = 150 mm
2
EPR-CSP to BS6195 4C
