DESIGN DATA
Compressor
Engine
1)
With filter change.
Designation
Number of compression stages 1
Designation
XAHS 146
XAHS 300
XATS 156
XATS 350
XAS 186
XAS 375
XAVS 166
XAVS 340
XAHS 186
XAHS 375
Make Deutz Deutz Deutz Deutz Deutz
Type
TCD3.6L4 TCD3.6L4 TCD3.6L4 TCD4.1L4 TCD4.1L4
Coolant
PARCOOL EG PARCOOL EG PARCOOL EG PARCOOL EG PARCOOL EG
Number of cylinders 44444
Bore mm 98 98 98 101 101
in 3.85 3.85 3.85 3.97 3.97
Stroke mm 120 120 120 126 126
in 4.72 4.72 4.72 4.96 4.96
Swept volume l 3.6 3.6 3.6 4.1 4.1
cu.in 219.6 219.6 219.6 250 250
Output according to 3046 IFN kW 80 80 80 105 105
BHP 107 107 107 140 140
- Load factor % 6565656565
Capacity of oil sump:
- Initial fill l 8.75 8.75 8.75 10.5 10.5
US gal 2.3 2.3 2.3 2.7 2.7
- Refill (max.)
1)
l 8881010
US gal 2.1 2.1 2.1 2.6 2.6
Capacity of cooling system l 1717172020
US gal 4.5 4.5 4.5 5.3 5.3
