- 60 -
COMPRESSOR /ENGINE SPECIFICATIONS
REFERENCE CONDITIONS
The inlet conditions are specified at the air inlet grating outside the canopy.
LIMITATIONS
Remarks
125. J1 Air required for engine and compressor cooling, combustion and for compression.
126. G9 With filter change.
130. C1 Free Air Delivery guaranteed according ISO 1217 ed. 4 2009 annex D with tolerance of +/-5% for (25l/s)(53cfm) < FAD
< (250l/s)(530cfm) and +/-4% for (250l/s)(530cfm) < FAD.
133. C At reference conditions unless otherwise stated.
138. B112 Cold start: compressor: PAROIL S i.s.o. PAROIL M Xtreme, engine: PAROIL E Mission Green, PAROIL E Xtra.
Designation Unit XAS 185 KD
Absolute inlet pressure bar 1
psi 14.7
Relative air humidity % 0
Air inlet temperature °C 20
°F 68
Normal effective working pressure bar 7
psi 100
Designation Unit XAS 185 KD
Minimum effective receiver pressure bar 4
psi 58
Maximum effective receiver pressure,
compressor unloaded
bar 9.3
psi 135
Maximum ambient temperature at sea level °C 48.9
°F 120
Minimum starting temperature °C -25
°F -13
Altitude capability see graph section
