- 26 -
Refinary equipment
Reference Name
K4 Relay kit 1604 3672 01
Y3 Air Shut-off Valve
1 Connect to digital high output in
cubicle default: H-OUT 10
2 Connect to 19 in cubicle
3 Connect to 24M in cubicle
