- 27 -
Etherstart Coldstart
Reference Name
K5 Etherstart relay
8 connect to D-IN07 in spare I/O box
Reference Name
1 Connect to relay on engine
2 Connect to 24 VDC in power supply
box
F14 circuit breaker 100A
