Atlas Copco XRXS 567 Cd User Manual

- 17 -
Reference Name
AFce Air Filter (compressor element)
AFe Air Filter (engine)
AFS Air Filter Switch
AOV Air Outlet Valves
AR Air Receiver
ATS Ambient Temperature Sensor
BBattery
BH Brake Handle
BS Battery Switch
CElp Compressor Element (low pressure)
CEhp Compressor Element (high pressure)
CLS Coolant Level Switch
CP Control Panel
CT Coolant Tank
CU Control Unit
DPar Drain Plug Air Receiver
DPce Drain Plug Compressor Element
DPeo Drain Plug Engine Oil
DPoc Drain Plug Oil Cooler
DPosv Drain Plug Oil Stop Valve
DPr Drain Plug Radiator
EEngine
EP Exhaust Pipe
Reference Name
ES Emergency Stop
ETS Element Temperature Sensor
FFan
FCeo Filler Cap (engine oil)
FCft Filler Cap (fuel tank)
FCc Filler Cap (coolant)
FFpc Fuel Prefilter Caterpillar
FFc Fuel Filter Caterpillar
FL Flash Light
FLG Fuel Level Gauge
FLS Fuel Level Sensor
FPco Filler Plug (oil compressor element)
FT Fuel Tank
IC Intercooler
IPS Interstage Pressure Sensor
LV Loading Valve
MPV Minimum Pressure Valve
OC Oil Cooler
OFce Oil Filter (compressor element)
OFe Oil Filter (engine)
OLG Oil Level Gauge
OT Oiltronix
R Radiator
Reference Name
RPS Regulating Pressure Sensor
RV Regulating Valve
SN Serial Number
SV Safety Valve
TB Towbar
WPS Working Pressure Sensor
