ALTITUDE UNIT PERFORMANCE CURVE
Max. allowable working pressure as a function altitude and ambient temperature.
XRXS 567 Cd - XRXS 1240 CD7
XRXS 607 Cd - XRXS 1275 CD7
0
3 281
6 562
9 843
13.124
0
1000
2000
3000
4000
-10 0 10 20 30 40 50
14 32 50 68 86 104 122
30 bar
435 psi
Altitude m
Altitude ft
Temperature °F
Temperature °C
XRVS 617 Cd - XRVS 1300 CD7
XRVS 647 Cd - XRVS 1350 CD7
0
3 281
6 562
9 843
13.124
0
1000
2000
3000
4000
-10 0 10 20 30 40 50
14 32 50 68 86 104 122
25 bar
363 psi
Altitude m
Altitude ft
Temperature °F
Temperature °C
