- 25 -
Operating instructions
PARKING, TOWING AND LIFTING
INSTRUCTIONS
Safety precautions
Attention
Uncouple vehicle.
Apply parking brake by moving the lever (1) in the
direction of the arrow.
Connect the safety chain (2) to the eyes (3) on the
towbar (4). You can move the towbar (4) upwards and
secure it by connecting the chain (5) to the eye (6).
Place the compressor as level as possible; however, it
can be operated temporarily in an out-of-level
position not exceeding 15°. If the compressor is
parked on sloping ground, immobilize the compressor
by placing wheel chocks (available as option) in front
of or behind the wheels.
Locate the rear-end of the compressor upwind, away
from contaminated wind-streams and walls. Avoid
recirculation of exhaust air from the engine. This can
cause overheating and engine power decrease.
The operator is expected to apply all
relevant Safety precautions.
Before putting the compressor in to use,
check the brake system as described in
section Brake adjustments.
After the first 100 km travel:
Check and retighten the wheel nuts and
towbar bolts to the specified torque. See
section Torque values.
Check the brake adjustment. See section
Brake adjustments.
When towing, lifting or transporting the
compressor in any way, the battery
switch must always be in the “OFF”
position!
Also switch off the preheater as this unit
is directly connected to the batteries.
PARKING INSTRUCTIONS WAGON
