- 53 -
Details of ECU triggered alarms can be monitored via the ECU DM1 LIST menu
In case of ECU AMBER LAMP or ECU PROTECT
LAMP:
Only possible when engine is running or if
Diagnostics Mode is active.
Access the ECU DM1 LIST menu via Alarm View.
In case of ECU RED LAMP:
Do NOT acknowledge the ECU RED LAMP alarm.
DM1 alarms are automatically copied into the
Alarm View, and can be read there.
For all ECU triggered alarms, the respective SPN code
is shown in the ECU DM1 LIST
A full list of supported SPN codes is provided by the
engine manufacturer.
For following alarms, the Xc controller also shows full
text next to the SPN code:
ECU - FUEL FILTER PRESSURE
ECU - INTERCOOLER TEMPERATURE
ECU - FUEL PRESSURE
ECU - FUEL FILTER PRESSURE
ECU - WATER IN FUEL
ECU - OIL LEVEL
ECU - OIL FILTER PRESSURE
ECU - OIL PRESSURE
ECU - TURBO BOOST PRESSURE
ECU - TURBO OIL PRESSURE
ECU - INTAKE MANIFOLD TEMPERATURE
ECU - AIR INLET PRESSURE
ECU - COOLANT TEMPERATURE
ECU - COOLANT LEVEL
ECU - SUPPLY VOLTAGE
ECU - AMBIENT AIR TEMPERATURE
ECU - AIR INLET TEMPERATURE
ECU - FUEL TEMPERATURE
ECU - OIL TEMPERATURE
ECU - ENGINE SPEED
ECU - INJECTOR 1
ECU - INJECTOR 2
ECU - INJECTOR 3
ECU - INJECTOR 4
ECU - INJECTOR 5
ECU - INJECTOR 6
ECU - INJECTOR 7
ECU - INJECTOR 8
ECU - SOOT LOAD
6981 INLET VALVE POS. FAILURE Shutdown Xc
7002 ECU COMMUNICATION Shutdown Xc
7007 ECU RED LAMP Shutdown ECU
7008 ECU AMBER LAMP Warning ECU
7009 ECU PROTECT LAMP Warning ECU
7010 ECU ENGINE SPEED TOO LOW Shutdown Xc
7020 ECU ENGINE SPEED ALARM 2 Shutdown Xc
7030 ECU ENGINE COOLANT TEMP. ALARM Controlled Stop Xc
7050 ECU ENGINE AIR INLET TEMP. ALARM 1 Controlled Stop Xc
7100 ECU DPF SOOT LOAD HIGH Warning Xc
7110 PLEASE FORCE DPF REGENERATION ! Inhibit Load Xc
7120 LOAD PREVENTION - HIGH DPF SOOT LOAD Controlled Stop Xc
7130 SOOT LOAD TOO HIGH - CALL ATLAS COPCO Warning Xc
7222 COMBO COMMUNICATION FAILURE Warning Xc
7223 COMBO PA SENSOR WARNING Warning Xc
7224 COMBO RHA SENSOR WARNING Warning Xc
7225 COMBO TA SENSOR WARNING Warning Xc
Alarmcode Alarmtext Failclass Trigger
