Atlas 210x User Manual

PC-100C VOLTAGE CHART
TERM STRIP
NUMBER
REC. TRANS.
1 (0) (0)
2
Gnd.
Gnd.
3
Gnd.
Gnd.
4
0.6(11
1.15(1)
5
Gnd.
Gnd.
6
Gnd.
Gnd.
7
0
0.33 (2)
8
Gnd.
Gnd.
9 N.C. N.C.
TERM. STRIP
NUMBER
REC. TRANS.
10 +13 +13
11
+13
+13
12
Gnd.
Gnd.
13
+11.8
+10.2
14
+7.3 (4)
+8.5 (4)
15
+3.0
+3.0
16
+3.0
+3.0
17
+13
+12.6
18 +13 +12.6
TERM. STRIP
NUMBER
REC. TRAMS.
19 +3 +12.6
20
+13
•
21
+3
+13
22
•
+12.6
Q101.
I.F. Amp.
Base
+4.0 161
+5.1
Collector
+12.216)
+9.4
Emitter +3.4 (6) +4.4
27
