Atlas 210x - Circuit Theory; PC-300 C Voltage Chart and Schematic

PC-200C VOLTAGE CHART
TERM. STRIP
NUMBER
REC. TRANS.
1 +13 +13
2 Gnd. Gnd.
3 +3.6 +3.3
4 Gnd. Gnd. -
5 • •
6 Gnd. Gnd.
7 0.5511) 0.53 (1)
8 Gnd. Gnd.
9 0 0.27 (3)
10 Gnd. Gnd.
11 0 0.05 (21)
12 Gnd. Gnd.
13 • 0.33 (21
14 • +6
15 Gnd. Gnd.
TERM. STRIP
NUMBER
REC. TRANS.
16
9
0.06 12)
17 0 0
18 Gnd. Gnd.
19 +3.5 +3.5
20 +2.6 +2.6
21 +10 +10
22 +2.6 +2.6
Q201,I.C.
I.F.Amp.
Term. 1-2-8 +10.4 +10.1
3-7 Gnd. Gnd.
4 +0.39 +0.37
5 +0.45 +0.43
6 +0.38 +0.36
TERM. STRIP
NUMBER
REC. TRANS.
Q202, I.C.
Mic. Amp.
Term. 1-5 • +5.3
2-4-14 • +4.2
3 • +3.5
6 • +2.1
7 e +1.5
8 0 +5.3
9 +3.4 +3.4
10 +2.7 +2.7
11 +9.8 +9.8
12 e +0.95
14 • +0.25
