MODEL 210x/215x CHASSIS COMPONENTS
PC-100C .. . . . ............. First I.F. Amplifier, First Mixer Printed Circuit Board
or PC
-
120 . . . . .
.....................
Optional Noise Blanker, 1st I FAmp , 1st Mixer
PC-200C . . . . . ........... Second I.F. Amplifier, Second Mixer, S-Meter Amplifier,
Mic Amplifier Printed Circuit Board
PC-300C . . . . . ............... Receiver Audio, Osc. Switch Printed Circuit Board
PC-400C . . . . . ............................... VFO Printed Circuit Board
PC-500D . . . . . . . SWR Protect, Pre-Amp, Driver, Power Amplifier Printed Circuit Board
PC-600 ...... ........................... Carrier Osc. Printed Circuit Board
PC-800C/1200 . ................... Receiver Input Tuning Printed Circuit Board
PC-820 ...... ................ 100 kHz Crystal Calibrator Printed Circuit Board
PC-900C . . . . . ................. Transmitter Input Tuning Printed Circuit Board
PC-1010/1020 . ........................ Low Pass Filters Printed Circuit Board
PC-1100A .... ................ SWR Bridge, Antenna Relay Printed Circuit Board
J1 ......... ........... 3 Conductor, Closed Circuit, Enclosed A.F. Output Jack
J2 ......... .................. 3 Conductor, Open Circuit, Enclosed Mic. Jack
J3 ......... ......................................... Banana Jack
j4 ......... ................................. 9 Pin Mica Tube Socket
j5 ......... .................................... Coaxial Receptacle
J6 ......... ................................. 9 Pin Mica Tube Socket
J7 ......... .............. 2 Conductor, Closed Circuit, Enclosed CW Key Jack
P1,P2 ...... ........................................ Banana Plugs
M1 ......... ........................... S-Units/P.A. Amps 500 uA Meter
FL1 ........ .................... 5520.3-5523.0 8 Pole Crystal Ladder Filter
S1,S2 ...... ..................................... SPDT Slide Switch
S3 ......... .............................. 1 Section, 5 Position Switch
S4 ......... .............................. 5 Section, 5 Position Switch
L1,L2,L3 .. . ......................................... 14V Lamps
E1 ......... ....................................... 4 Ohm Speaker
C1 ..... ........... 470PF 5% SM R1 . . . . . .......... 47K 10% 1/4W
C2,3,5 . ........ .01 MF 100V Disc R2,8,15 ........... 1K 10% 1/4W
C4 ..... ....... .22MF 100V Mylar R3 . . . . . ......... .3.3K 10% 1/4W
C6 ..... .......... .IMF 50V Disc R4 ..... ....... 10K A.F. Gain Pot.
C7 ..... ..... 1000MF 25V Electro. R5 ..... ......... .4.7K 10% 1/4W
D1 ..... . . . . . 1N4148 Silicon Diode R6 ..... ....... 10K, R.F. Gain Pot.
D2 ..... . . 1N5221 2.4V Zener Diode R7 ..... .......... 47010% 1/2W
L1 ...... ............ .1uH Toroid R9 ..... ............. 105%1W
Q1 ...... , . . 78L06AC I.C. Volt. Reg. R10 . . . . ............. 275% 1W
R11,12 . 10K,ALC,Mic.Gain Dual Pot
R13 .. .. .......... 10K 10% 1/4W
R14 . . .. .......... 10K 10% 1/4W
