Atlas BP12000X User Manual

Parts List 33
BP12000X
Item Part# Description Qty.
30A 207012A Outer lifting arm 4
30B 207013A Middle lifting arm 4
30C 207014A Inner lifting arm 4
31 201002 Hex bolt 16
32 217114A Rubber pad assembly 4
32A 420138 Socket bolt 4
32B 209134 Rubber Pad 4
32C 680030B Rubber Pad frame support assembly 4
33 206032 Snap Ring 4
34 206036 Hair Pin 4
35 217044 Arm lock 4
36 217045A Spring 4
37 217046B Left arm lock bar 2
38 217046C Right arm lock bar 2
39 209153 Arm lock bar ring 4
40 201010A Chain connector 4
41 207015 Chain 2
42 209038 Hex bolt 2
43 207016 Top plate assembly 2
44 217037 Pin for bottom pulley 2
45 217036 Big Pulley 2
46 207054 Offside column 1
47 207018 Offside safety cover 1
48 209051B Adapter 1.5″ 4
49 209052B Adapter 2.5″ 4
50 209053B Adapter 5″ 4
51 217069 Hex bolt 8
52 206006 Washer 12
53 206023 Self locking nut 8
54 620065 Shim 10
54A 201090 Shim 10
55 206002 Pin for safety lock 2
56 209007A Safety Spring 2
57 209010 Snap ring 2
58 209011 Plastic small pulley 2
59 207019 Power side safety lock 1
