Parts List 32
BP12000X
Parts List
Item Part# Description Qty.
1 207001 Floor cover 1
2 207002 Short extension cover 2
3 207003 Long extension cover 2
4 217019 Top pulley 4
5 217020 Bronze bush for pulley 6
6 209012 Hair pin 6
7 209005 Self locking nut 8
8 209033 Washer 24
9 209043 Hex bolt 4
10 207053 Power side column 1
203 440035 Power unit 1
12 209009 Cup head bolt 12
13 207005 Powerside lock cover 1
14 420132A Bronze bush for chain pulley 4
15 201005 Split Pin 2
16 207006 Pin for Chain pulley 2
17 207007 Chain pulley 2
18 207008 Chain pulley bracket assembly 2
19 207009A Carriage 2
20 207010 Cylinder 2
21 217188 Slider block 16
22 207047 Carriage plastic cover 2
23 217053 Protective Rubber 2
24 209019 Screw 12
25 217047B Arm pin 4
25A 520023 Snap spring 4
26 206048 Socket bolt 12
27 209039 Lock washer 14
28 209022 Washer 14
29 206049 Moon gear 4
30 207011A Lifting arm 4
