Atlas BP12000X User Manual

Parts List 35
BP12000X
Parts For Hydraulic Cylinder
Item Part# Description Qty.
20-1 207027 Piston rod 2
20-2 207028 Piston 2
20-3 206069 O-Ring 2
20-4 620053 Support Ring 2
20-5 620054 Y-Ring 2
20-6 630027 O-Ring 2
20-7 206071 Hex nut 2
20-8 207029 Adjustment tube 2
20-9 217078 Dust ring 2
20-10 520058 O-Ring 2
20-11 207030 Head cap 2
20-12 201034 Bleeding Plug 2
20-13 207031 O-Ring 2
20-14 207032 Bore weldment 2
Atlas Hydraulic Power Unit
Item Part# Description Qty.
201-1 81400032 Motor 1
201-2 81400159 Protective Ring 1
201-3 81400063 Motor Connecting Shaft 1
201-4 81400031 Valve Body 1
201-5 81400160 Relief Valve 1
201-6 81400161 Lock Washer 4
201-7 81400162 Socket Bolt 4
201-8 81400121 Inlet Pipe 1
201-9 81400163 O-Ring 1
201-10 81400164 Filter 1
201-11 81400165 Hex bolt 4
201-12 81400093 Reservoir 1
201-13 81400166 Cross Bolt 2
201-14 81400167 Cover of Capacitor 1
201-15 81400087 Capacitor 1
