AT89STK-11 Hardware User Guide 4-13
7676B–8051–08/07
Appendix B: Bill of Materials
4.1 Bill of Materials
Table
Item Q.ty Reference Part Tech. Caracteristics Package Manufacturer
1
29
CD1,CD2,C2,CD3,C3,C4,
100n 50V-10% Ceramic CASE 0805 PHYCOMP
CD5,C5,CD6,C6,CD7,C7,C8,
C9,C10,C11,C12,C13,C16,
C17,C18,C19,C20,C21,C22,
C23,C24,C25,C26
2 1 C1 1µF 10Vmin ±10% Case A AVX
3 2 C14,C15 22pF 10Vmin ±10%
EIA/IECQ
3216
PHYCOMP
4 1 D1 Red Led I=10 mA Agilent
®
5 11 D2,D3,D4,D5,D6,D7,D8,D9,
Green Led I=10 mA Agilent
D10,D11,D12
6 1 J1 SIP2 SOCKET . Pitch 2.54mm Molex
®
7 1 J2 CONNECTOR JACK PWR Int.Diam=2.1mm
Int. Diam.
2.1mm
Cliff
®
8 1 J3 HEADER 31x2/SM
9 2 J4,J8 HEADER 3X2 BARRETTE SECABLE Pitch 2.54mm Tyco Elec. / AMP
10 3 J5,J6,J10 HEADER 5X2 BARRETTE SECABLE Pitch 2.54mm Tyco Elec. / AMP
11 1 J7 CONNECTOR SIP6 RA . . .
12 1 J9 SIP4 . . .
13 3 J11,J12,J13 JUMPER Pitch 2.54mm Tyco
™
Elec. / AMP
13bis 3 JUMPER shunt Pitch 2.54mm Arwin
14 1 P1 SUB-D9 FEMALE 90° with harpoons Tyco Elec. / AMP
15 1 R1 270 1/16W-5% SMD Case 0603 Multicomp
16
14
R2,R5,R14,R15,R16,R17,
1K 0.06W, 5% Case 0603 MulticompR18,R19,R20,R21,R22,R23,
R24
17 1 R3 820 1/16W-5% SMD Case 0603 Multicomp
18 8 R4,R6,R8,R9,R10,R11,R12,
10k 0.06W, 5% Case 0603 Multicomp
R13
19 4
SP1,SP2,SP3,SP4,SP5, SP6,
SP7, SP8, SP9, SP10, SP11,
SP12
SolderPad
20 8 SW1,SW2,SW3,SW4,SW5,SW6,
PUSH-BUTTON SMD, rectangular See DS ITT Canon
®
SW7,SW8
To Next Page
