AT89STK-11 Hardware User Guide 2-4
7676B–8051–08/07
Section 2
Hardware Description
2.1 Board Overview
Figure 2-1 shows the AT89STK-11 board.
Figure 2-1. AT89STK-11
This photo is not contractual and may be modified without notification by Atmel.
