251
8271D–AVR–05/11
ATmega48A/PA/88A/PA/168A/PA/328/P
23.3.3 DIDR1 – Digital Input Disable Register 1
• Bit 7:2 – Reserved
These bits are unused bits in the ATmega48A/PA/88A/PA/168A/PA/328/P, and will always read
as zero.
• Bit 1, 0 – AIN1D, AIN0D: AIN1, AIN0 Digital Input Disable
When this bit is written logic one, the digital input buffer on the AIN1/0 pin is disabled. The corre-
sponding PIN Register bit will always read as zero when this bit is set. When an analog signal is
applied to the AIN1/0 pin and the digital input from this pin is not needed, this bit should be writ-
ten logic one to reduce power consumption in the digital input buffer.
Bit 76543210
(0x7F) ––––––AIN1DAIN0DDIDR1
Read/Write RRRRRRR/WR/W
Initial Value 00000000
