ATmega48A/PA/88A/PA/168A/PA/328/P

(0xBF) Reserved – – – – – – – –

(0xBE) Reserved – – – – – – – –

(0xBD) TWAMR TWAM6 TWAM5 TWAM4 TWAM3 TWAM2 TWAM1 TWAM0 –246

(0xBC) TWCR TWINT TWEA TWSTA TWSTO TWWC TWEN –TWIE 243

(0xBB) TWDR 2-wire Serial Interface Data Register 245

(0xBA) TWAR TWA6 TWA5 TWA4 TWA3 TWA2 TWA1 TWA0 TWGCE 246

(0xB9) TWSR TWS7 TWS6 TWS5 TWS4 TWS3 –TWPS1TWPS0 245

(0xB8) TWBR 2-wire Serial Interface Bit Rate Register 243

(0xB7) Reserved – – – – – – –

(0xB6) ASSR – EXCLK AS2 TCN2UB OCR2AUB OCR2BUB TCR2AUB TCR2BUB 166

(0xB5) Reserved – – – – – – – –

(0xB4) OCR2B Timer/Counter2 Output Compare Register B 164

(0xB3) OCR2A Timer/Counter2 Output Compare Register A 164

(0xB2) TCNT2 Timer/Counter2 (8-bit) 164

(0xB1) TCCR2B FOC2A FOC2B – – WGM22 CS22 CS21 CS20

163

(0xB0) TCCR2A COM2A1 COM2A0 COM2B1 COM2B0 – –WGM21WGM20 160

(0xAF) Reserved

– – – – – – – –

(0xAE) Reserved

– – – – – – – –

(0xAD) Reserved – – – – – – – –

(0xAC) Reserved

– – – – – – – –

(0xAB) Reserved

– – – – – – – –

(0xAA) Reserved – – – – – – – –

(0xA9) Reserved – – – – – – – –

(0xA8) Reserved – – – – – – – –

(0xA7) Reserved – – – – – – – –

(0xA6) Reserved – – – – – – – –

(0xA5) Reserved – – – – – – – –

(0xA4) Reserved – – – – – – – –

(0xA3) Reserved – – – – – – – –

(0xA2) Reserved – – – – – – – –

(0xA1) Reserved – – – – – – – –

(0xA0) Reserved – – – – – – – –

(0x9F) Reserved – – – – – – – –

(0x9E) Reserved – – – – – – – –

(0x9D) Reserved – – – – – – – –

(0x9C) Reserved – – – – – – – –

(0x9B) Reserved – – – – – – – –

(0x9A) Reserved – – – – – – – –

(0x99) Reserved – – – – – – – –

(0x98) Reserved – – – – – – – –

(0x97) Reserved – – – – – – – –

(0x96) Reserved – – – – – – – –

(0x95) Reserved – – – – – – – –

(0x94) Reserved

– – – – – – – –

(0x93) Reserved

– – – – – – – –

(0x92) Reserved – – – – – – – –

(0x91) Reserved

– – – – – – – –

(0x90) Reserved

– – – – – – – –

(0x8F) Reserved

– – – – – – – –

(0x8E) Reserved – – – – – – – –

(0x8D) Reserved

– – – – – – – –

(0x8C) Reserved

– – – – – – – –

(0x8B) OCR1BH Timer/Counter1 - Output Compare Register B High Byte 140

(0x8A) OCR1BL Timer/Counter1 - Output Compare Register B Low Byte 140

(0x89) OCR1AH Timer/Counter1 - Output Compare Register A High Byte 140

(0x88) OCR1AL Timer/Counter1 - Output Compare Register A Low Byte 140

(0x87) ICR1H Timer/Counter1 - Input Capture Register High Byte 140

(0x86) ICR1L Timer/Counter1 - Input Capture Register Low Byte 140

(0x85) TCNT1H Timer/Counter1 - Counter Register High Byte 140

(0x84) TCNT1L Timer/Counter1 - Counter Register Low Byte 140

(0x83) Reserved

– – – – – – – –

(0x82) TCCR1C FOC1A FOC1B

– – – – – –139

(0x81) TCCR1B ICNC1 ICES1

– WGM13 WGM12 CS12 CS11 CS10 138

(0x80) TCCR1A COM1A1 COM1A0 COM1B1 COM1B0 – –WGM11WGM10 136

(0x7F) DIDR1

– – – – – –AIN1DAIN0D 251

(0x7E) DIDR0

– – ADC5D ADC4D ADC3D ADC2D ADC1D ADC0D 268
