Figure 30-133.ATmega88A: Calibrated 8MHz RC Oscillator Frequency vs. OSCCAL Value
30.3.12 Current Consumption of Peripheral Units
Figure 30-134.ATmega88A: ADC Current vs. V
CC
(AREF = AV
CC
)
85 °C
25 °C
-40 °C
0
2
4
6
8
10
12
14
0163248 64 8096112128 144 160 176 192 208 224 240 256
OSCCAL (X1)
F
RC
(MHz)
85 °C
25 °C
-40 °C
0
50
100
150
200
250
300
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
