ATmega48A/PA/88A/PA/168A/PA/328/P
Figure 30-235.ATmega168A: Minimum Reset Pulse width vs. V
CC
30.6 ATmega168PA Typical Characteristics
30.6.1 Active Supply Current
Figure 30-236.ATmega168PA: Active Supply Current vs. Low Frequency (0.1-1.0MHz)
85 °C
25 °C
-40 °C
0
250
500
750
1000
1250
1500
1750
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Pulsewidth (ns)
5.5 V
5.0 V
4.5 V
4.0 V
3.3 V
2.7 V
1.8 V
0
0.2
0.4
0.6
0.8
1
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I
CC
(mA)
