Atmel SAME70-XPLD User Manual

Designator Mounted From To Comments
R217 Yes PA6 J503 - Pin 4 Arduino DUE Pin 139
R218 No PD10 J503 - Pin 4 Arduino DUE Pin 139
R219 Yes PD24 J504 - Pin 1 Arduino DUE Pin 88
R220 Yes PA10 J504 - Pin 2 Arduino DUE Pin 89
R221 Yes PA22 J504 - Pin 3 Arduino DUE Pin 90
R222 No PA13 J400 - Pin 5 Camera Module Reset
Command
R223 No PD22 J400 - Pin 18 ISI Interface: Data Line 0
R224 No PB3 J402 - Pin 15 Chip Select for USART in SPI
Mode with Master Mode
R225 No PD31 J402 - Pin 15 Chip Select for USART in SPI
Mode with Master Mode
R226 No PB2 J402 - Pin 15 Chip Select for USART in SPI
Mode with Slave Mode
R227 No J402 - Pin 17 PB0 MISO for USART in SPI Mode
R228 No PB1 J402 - Pin 16 MOSI for USART in SPI Mode
R229 No PB13 J402 - Pin 18 SPI Clock for USART in SPI
Mode
R230 Yes PD22 J402 - Pin 18 SPI Interface: Clock Line
R234 Yes PD16 J505 - Pin 6 Arduino DUE Pin 6
R235 Yes PD21 J402 - Pin 16 SPI Interface: MOSI Line
R236 No PC12 J502 - Pin 8 Arduino DUE Pin 85
R400 Yes PB6 J406 - Pin 7 SWDIO for JTAG Interface
R401 Yes PB7 J406 - Pin 9 SWCLK for JTAG Interface
R402 Yes J406 - Pin 15 TARGET_RESET Reset From JTAG Interface
R403 Yes PB5 J406 - Pin 13 TRACESWO for JTAG Interface
R623 No VCC_5V0 VIN For 5V supply of any shield
R624 Yes SAM E70 Pin 3 VDDOUT Node LDO Output for current
measurement
Atmel SAME70-XPLD [USER GUIDE]
Atmel-44050A-SAME70-XPLD_User Guide-12/2015
39
