Atmel SAME70-XPLD User Manual

1. Introduction
This user guide introduces the Atmel SAME70-XPLD evaluation kit and describes the development and
debugging capabilities for applications running on a SAM E70 ARM-based embedded microcontroller.
1.1. Kit Contents
• Boards
– One SAME70-XPLD board
• Cables
– One Micro-AB type USB cable
1.2. Related Items
• Atmel SAM E70 Series Datasheet
1.3. Kit Overview
1.3.1. Evaluation Kit Architecture
Figure 1-1 Evaluation Kit Architecture
SDRAM
16Mb SDRAM
ETHERNET
Ethernet 10/100 Interface
SDCARD
4-bit SDCARD
Reader Interface
USB DEBUG
USB Micro A/B Connector
ATMEL EDBG
Atmel Embedded Debugguer
JTAG
20-Pin JTAG Connector
ARDUINO CONNECTORS
8-Expansion Headers
Arduino R3 compatible PIO Signals
(Not Populated)
XPRO CONNECTORS
3-Expansions Headers
Compatible with Atmel XPRO Extensions
TARGET USB
USB Micro A/B Connector
CAMERA MODULE
Camera Interface Connector
for CAMx-EB Camera Module series
(Not Populated)
TRACE
20-pin debug connector
For Trace
(Not Populated)
EEPROM
I²C - 2k-bit serial EEprom
And Unique 128-bit serial number
AT24MAC402
Atmel SAME70-XPLD [USER GUIDE]
Atmel-44050A-SAME70-XPLD_User Guide-12/2015
3
