Atmel SAME70-XPLD User Manual

1.3.2. Evaluation Kit Specifications
Table 1-1 Evaluation Kit Specifications
Characteristic Specifications
Temperature Operating 0°C to +70°C
Storage -40°C to +85°C
Relative Humidity 0 to 90% (non-condensing)
RoHS status Compliant
Ordering code ATSAME70-XPLD
1.3.3. Board Features
Table 1-2 Board Specifications
Characteristics Specifications
PCB characteristics 83.5 × 105 × 16mm (4 layers)
Processor ATSAME70Q21 (144-lead LQFP package) ARM Cortex-M7 Processor.
Processor clock sources 12 MHz crystal oscillator
32.768 kHz crystal oscillator (not populated)
EEPROM One AT24MAC402 EEPROM
SDRAM One IS42S16100E 16 Mb SDRAM
SD/MMC One 4-bit SD card connector
USB One Micro-AB USB device
One Micro-AB USB for EDBG debug interface
Camera interface Camera Extension Header for connection with ISI Modules (not populated)
Ethernet One Ethernet PHY (RMII 10/100)
Debug port One JTAG interface connector
One ETM Trace interface connector (not populated)
Expansion connectors Three Atmel XPRO Extension Headers
Arduino R3 compatible set of headers (not populated)
GPIO,TWI, SPI, USART, UART and Audio interfaces are accessible via these
headers
Board supply voltage 5V from USB target, from USB Debug or from Arduino shield
On-board power regulation is performed by a 3.3V LDO
User interface Reset and free user pushbutton
One green user LED
1.3.4. Board Overview
The Atmel SAME70-XPLD is a hardware platform to evaluate the Atmel ATSAME70Q21.
Atmel SAME70-XPLD [USER GUIDE]
Atmel-44050A-SAME70-XPLD_User Guide-12/2015
4
