Atom S100 Series - Optional Accessories; Recommended Spare Parts

19
Features of working and NOT OPERATIVE machine
Leq < 70 dB (A)
Lpc < 130 dB (C)
Features of working and OPERATIVE machine:
1) Hide, thickness 1.5 mm at 10 SPM
with 1 layer Leq = 75 dB (A) and Lpc < 130 dB (C)
2) Imitation leather, thickness 1.5 mm at 10 SPM
with 4 layers Leq = 77 dB (A) and Lpc < 130 dB (C)
NOTE
Theindexleveldependsonthecarryingoutworking(aswellasonthemachinesettingupconditions);theindexlevelsofanyworkingarereportedas
an example.
CAPTION
Leq: equivalent continuous level of acoustic pressure at operator site
Lpc: level of sound pressure peak at operator site
The machine can be equipped with the following optional accessories:
cutting complement: Identicut
simple cut--counting device
programmed cut--counting device
complete kit of wrenches and tools
side tables
On completion we also advise the following list of spare parts (according to decreasing priority):
-- n. 2 push--button micro switches (code 02E03927);
-- n. 2 push--button cover (code 02E03986);
-- n. 1 printed circuit board (code 02E03947);
-- n. 1 potentiometer push--button No.1 (code 02001422);
-- n. 1 potentiometer push--button No.3 (code 02001422);
-- n. 1 insert for joint (code 02003628);
-- n. 1 electromagnet (code 02001746);
-- n. 1 oil flexible pipe (code 02003636);
-- n. 1 set of piston ram seals (for S/SE108: codes 02001782+02001784+02001150);
(for S/SE116/120C: codes 02001154 + 02001155 + 02001210);
(for S/SE120: codes 02002099 + 02000789 + 02002098);
(for S/SE122/124C/124/125C/125/125L: codes 02001223 + 02001222 + 02001236);
-- n. 1 gear pump (for S/SE108: code 02001196 (50Hz) -- code 02001162 (60Hz));
(for S/SE116/120C: code 02003899 (50 Hz) -- code 02003898 (60 Hz));
(for S/SE120/122/124C/124/125C/125/125L: code 02003900 (50 Hz) -- code 02003899 (60 Hz));
-- n. 1 oil filter (code 01000133);
and the following wear material:
-- n. 1 cutting board (for S/SE108: code 02001164);
(for S/SE116: code 02001209);
(for S/SE120C: code 02001185);
(for S/SE120/124C/125C: code 02002625);
(for S/SE124/125/125L: code 02001186);
(for S/SE122: code 02001563);
n.1 arm plate (for S/SE108: code 01002056);
(for S/SE116/120C/120/124C: code 01011453);
(for S/SE124: code 01001587);
(for S/SE125C: code 01011490);
(for S122/125: code 01001588);
(for S125L: code 01001601);
-- n.12 screws (for S/SE108/116/120C/120/124C: code 02000526);
(for S/SE122/124/125C/125/125L: code 02000585);
-- n.12 washers (code 02000338);
-- n.12 nuts (code 02000121).
139 Acoustic emission of the machine
GB
140 Optional accessories
GB
141 Recommended spare parts
GB
