16
In case of an electric black- out, as well as on machine turning off, the hydraulic pump stops completely in 40 seconds approx. and the
rotating arm begins its slow descent (Fig. 18). Therefore it is necessary that in such events the operator takes care not toleave anypart
of his body or any other object between the cutting table and the turning arm.
Fig. 18
TheCutting Emergency devicetimesthecuttingstroke,anditisrecommendedjustincasethe automaticstroke endis damagedor whenvery
small cutting dies are used.
Fig. 19
Device activation:
1) Lower the switch lever, placed on the electrical equipment box, to the Cutting Emergency position (Fig. 19).
In case of clicking presses equipped with a single potentiometer (SE Series):
2)Resetthepotentiometerand,afterhavingplacedthecuttingdieonthemachinecuttingtablewithoutanymaterial inbetween, bymeans ofthe
turning arm adjustment wheel place the turning arm at 15 ÷ 20 mm from the cutting die.
3)Bymeansofthepotentiometergraduallyincreasethevaluetillwhenitispossibletocarryourthecuttingphase bypressing thepush--buttons
at the same time.
In case of clicking presses equipped with the three- push- button- unit and two potentiometers (S100 Series):
4) Reset thevalues ofboth potentiometersand, afterhaving positionedthe dieon themachine cuttingtable withoutany materialin between,by
means of the turning arm adjustment wheel, place the turning arm at 15 ÷ 20 mm from the cutting die.
5)Bymeansofthepotentiometerconnectedtopush--button1graduallyincreasethevaluetillwhenitispossibletocarryourthecuttingphaseby
pressing at the same time this push--button and the single push--button on the right--hand side of the arm.
6)Inbothpreviouscasesthesetvaluecanchangeaccordingtothematerialorwhenacuttingdieisused,whichhasadifferentsize,buttheSAME
HEIGHT.
7)Ifcuttingdiesareused,havingadifferentheightincomparisonwiththedieusedforthestartingadjustment,itisnecessarytorepeattheoperations
previously described at points 2 -- 3 or 4 -- 5.
8) Move the switch lever to NORMAL position when the clicking press uses the standard AUTOMATIC STROKE END.
For a good machine efficiency it is advisable to carry out the following maintenance operations periodically:
a) turn upside--down the cutting pad (for S/SE108: code 02001164; for S/SE116: code 02001209; for S/SE120C: code 02001185; for
S/SE120/124C/125C: code 02002625; for S124/125/125L: code 02001186; for S122: code02001563, tav.1) everyweek andplane itwhenever
there are wears or sinkings of approx. 2 mm;
b) turnupside--downandfront--backthealuminiumplateonthearm(forS/SE108:code01002056;forS/SE116/120C/120/124C:code01011453;
forS/SE124:code01001587;forS/SE122/125:code01001588;forS/SE125C:code01011490;forS125L:code01001601,tav. 3)at leastevery
3 months to guarantee the flatness of the contact surface and its gradual wear;
c) clean withacloth (whichleavesnothread) theseal collaron thecolumn (forS/SE108: code01002005; forS/SE116/120C: code01010413;
for S/SE120/122/124C/124/125C/125/125L: code 01001367, tav. 1) from residuals and dusts of cut materials every month (Fig. 20);
Fig. 20
134 RESIDUAL RISK on machine switching off
GB
135 Cutting Emergency
GB
136 Periodical maintenance
GB
