Atom S100 Series - Technical Data

18
Fig. 25
3º TROUBLE: Breaking of the cable setting arm ascent/descent
a) The breakingof the steel cable (code 01001567, tav.4--5--6) causes the immediate ascent of the arm beyond the maximum limit (Fig. 26).
Immediately switch off the motor, to avoid its burning out, and replace the damaged part.
Fig. 26
4º TROUBLE: The rotating arm moves down but does not cut
a) Check thatthere isno leakageunderpressurefrom thedelivery pipe(code 02003636, tav.4--5--6) andfrom thepertinent mechanicfittings
while the machine is trying to cut (left Fig. 27).
b) Also check if there is any oil leakage under pressure from the pump (for S/SE108: code 02001196 (50Hz) -- code 02001162 (60Hz); for
S/SE116/120C: code 02003899 (50Hz) -- code 02003898 (60Hz); for S/SE120/122/124C/124/125C/125/125L: code 02003900 (50 Hz) -- code
02003899 (60 Hz), tav. 4--5--6) (right Fig. 27).
Fig. 27
S 108 S 116 S120C S120 S122 S124C S124 S125C S125 S125L
Maximum cutting power
ton
kN
8
78
20
196
20
196
22
216
22
216
25
245
25
245
25
245
25
245
25
245
Cutting table
mm
600x300 800x400 900x430 900x450 1200x500 900x450 1000x500 900x450 1000x500 1000x500
Useful area % 99 97 98 94 94 94 95 98 97 97
Arm width mm 300 370 370 370 500 370 370 500 500 610
Arm speed:
approach
m
m
/
s
1
4
0
1
4
6
1
9
7
1
2
4
a
p
p
r
o
a
c
h
cut
ascent
m
m
/
s
1
4
0
45
63
1
4
6
51
79
1
9
7
53
71
1
2
4
45
71
M
o
t
o
r
p
o
w
e
r
HP
1
M
o
t
o
r
p
o
w
e
r
H
P
kW
1
0.75
Weight (with oil) Kg 430 610 630 880 1060 880 990 900 1030 1050
Weight (with pallet) Kg 450 630 650 910 1090 910 1020 920 1060 1080
Weight(withseapacking) Kg 500 725 745 1000 1200 1000 1120 1020 1160 1180
Dynamic overload Kg + 75
Hydraulic oil
Kg
~ 24 ~ 25 ~ 38
138 Technical data
