12
Tofitintwoironbarsintotheholesmadeinthemachine backroom accomodationand liftthe machineby twosuitable safetyslings (seeFig. 3).
We recommend not to lift the machine more than 50 cm. ( ~ 20 in.) max. Avoid that people not in charge stand close to the machine.
Fig. 3
25 mm
300 mm
max. 50 cm.
Hookitthrough thesuitable hookingplates locatedon thesides ofthe cuttingtable withthe FOURscrews, tightlyclamped. Incase ofeyebolts,
thesearelocatedinthemachinebackroomaccomodation.Toavoiddamagestothemachinesbase,slowlyliftitupbecauseitwillquicklytakean
inclinedposition(centreFig. 4).We recommend not to lift the machine more than 50 cm. (~ 20 in.) max. Inbothcasesavoidthatpeoplenot
in charge stand close to the machine.
Toavoidsuddenanddangerousdisplacementsofthearmwhichcoulddamagetheropesduringlifting,stopthearmin centralposition bymeans
of wedges to be taken away only on switching on the machine (left Fig. 4).
Fig. 4
max. 50 cm.
max. 50 cm.
Beforeputtingdownthemachine,checkthatthesurface,whichwillsupportit,isflatandwithout flammableand/or viscousliquids (gasoline,oil,
etc.)onit.Theclickingpressneedsnospecialanchoringtotheground;itissufficienttoinserttheshockabsorbers,deliveredalongwiththemachine,
into the holes suitably drilled in the machine base (Fig. 5).
Fig. 5
125 Machine lifting (S/SE116/120C)
GB
126 Machine lifting (S/SE108/120/122/124C/124/125C/125/125L)
GB
127 Machine positioning
GB
