TOGGLE SWITCHES
CONTINUED...
Any preset can be loaded in to any of
these nine positions. We’ve labeled the
switches STYLE and CHANNEL to provide
a logical organization. For example, you
should think of STYLE postitions as:
= Clean = Crunch = Lead
In the Clean STYLE position we’ve
loaded these presets in the three
CHANNEL positions:
1 = D Luxe
3 = Top Boost
2 = ’59 Bman
In the Crunch STYLE position we’ve
loaded these presets in the three
CHANNEL positions:
1 = Kornfield
2 = Rumble Brite
3 = Hot Brit
In the Lead STYLE position we’ve
loaded these presets in the three
CHANNEL positions:
1 = 5051
2 = HBE
3 = Recto
See the Presets section of the
manual for more info.
CAB 1/4”/CAB XLR – This is also a
three postition toggle switch. The
setting of this switch determines if the
speaker cabinet impulse respose is
active on the 1/4” output, XLR output
or both. For live playing, you may have
the 1/4” output feeding a power amp
and speaker cabinet for your own
stage monitoring, while the XLR output
would feed the P.A. system.
In this scenario, you would want
this switch in position 3 so that the
speaker cabinet impulse respose is
only active on the XLR output.
1 =CAB on 1/4” output only
2 =CAB on both outputs
3 =CAB on XLR output only
EFFECTS AND
SIGNAL CHAIN
AMPLIFIRE-BOX offers studio-quality
effects developed by Studio Devil. They
are arranged into the following signal
chain categories (Editor designation is
noted in parentheses):
NOISE GATE (GTE)
COMPRESSOR (CMP)
PRE EQ (PRE)
DISTORTION / SCREAMER /
OVERDRIVE/ FUZZ / CLEAN BOOST
(BST)
PARAMETRIC EQ / PROGRAMMABLE
FILTER (PQ1/2/3)
REVERB (RVB)
The order of these effects cannot be
changed. The noise gate, compressor
and boost effects come before the
amp block and the reverb effect comes
after the amp block. However, the
EQ function has one band dedicated
before the amp block and three other
bands that can be assigned either pre
or post amp block. For more info see
the EQ section of the editor..
