Atomic G01889W - Hardware and Accessories Identification; Hardware Identifier

HARDWARE IDENTIFIER
( To Scale)
©
2012 Escalade Sports
For Customer Service Call 1-888-996-2729
3
All Rights Reserved.
H1 - 5/16” x 1-1/2”
Allen Head Bolt
(8 pcs)
H2 - 5/16” x 1-1/4”
Allen Head Bolt
(16 pcs)
H3 - 5/16”
Flat Washer
(24 pcs)
H5 - #4 x 2”
Phillips Flat
Head Screw
(6 pcs)
H6 - #4 x 5/8”
Phillips Round
Head Screw
(6 pcs)
(Not to Scale)
H7 - #4 x 1/2”
Phillips Round
Head Screw
(20 pcs)
H9 - #3 x 15mm
Phillips Flat Head
Screw (8 pcs)
H10 - #4 x 1”
Phillips Round Head
Bolt (26 pcs)
T1 - Allen Wrench
(1 pc)
ACCESSORIES IDENTIFIER
( Not to Scale)
A1- Soccer Ball (4 pcs)
!
WARNING:
CHOKING HAZARD
Small parts.
Not for children under 3 yrs.
H4 - #3.5 x 1-1/2”
Phillips Washer
Head Screw
(12 pcs)
H8 - 3/16” x 5/8”
Phillips Round
Head Bolt
(8 pcs)
H11 - #4
Lock Nut
(26 pcs)
