ATOMSTACK R3 Rotary Roller - Synchronized Belt Placement

Shenzhen AtomStack Technologies Co., Ltd. support@atomstack3d.com
4.13 Connection plug on rotary roller 4.14 White plug wire
4.15 black plug wire
3. The synchronized belt must be set out of the processing area, make sure will not be
destroyed by the laser during the operation.
4.18 Rotary roller and synchronized belt
Connection
socket
Plug for roller
Plug for motor
4PIN white plug wire
Plug for roller
Plug for motor
4PIN black plug wire
Laser Head
R3 Rotary Roller
Roller
Synchronized belt
Out of processing area
