ATOMSTACK R3 Rotary Roller User Manual

Shenzhen AtomStack Technologies Co., Ltd. support@atomstack3d.com
Table of Contents
1. Security Statement 3
1. Security of Laser 3
2. Security of Fire Fighting 3
3. Security of Material 3
4. Security of Operation 3
2. Disclaimer and warning. 4
3. AtomStack R3 Rotary Roller Introduction 5
4. AtomStack R3 rotary roller software installation and use 6
4.1. LaserGRBL software installation and operation 6
1 Software download 6
2 Install LaerGRBL 6
3 LaserGRBL pulse adjustment 6
*A. Laser engraver connect with LaserGBRL 6
*B. Grbl Selection 7
*C. X/Y axis pulse value setting 7
4.2 LightBurn installation and pulse value setting 7
1 Software download 7
2 Install LightBurn 8
3 LightBurn pulse adjustment 8
*A. Laser engraver connect with LightBurn 8
*B. Edit selection 8
*C. Outputs Setup data sheet 9
*D. X/Y axis pulse value setting 9
5. R3 Rotary Roller setting 10
1. Definition for raiser of R3 Rotary Roller and Laser engraver 10
2. Cable explanation of of R3 Rotary Roller and Laser engraver 10
3. Definition of working scope for the synchronized belt 11
4. Definition for X axis of R3 Rotary Roller and Laser engraver 12
5. Gear Definition of R3 Rotary Roller 14
6. Precautions 15

ATOMSTACK R3 Rotary Roller Specifications

General

Brand	ATOMSTACK
Model	R3 Rotary Roller
Category	Industrial Equipment
Language	English
