ATS Co-Pilot - Dip Switch Configuration Guide

Di
p switch selection:
---------------------------------------------------------------------------------------------------------------------------------------
Switch #1
If your Dodge’s transmission has a stock valve body flip #1 switch to ON position
If your Dodge’s transmission has an ATS valve body flip #1 switch to OFF position
---------------------------------------------------------------------------------------------------------------------------------------
Switch #2
A
utomatically cancels OD from a stop, only cancels after ignition has cycled, cancels at speed
above 3mph.
IMPORTANT: If the white wire of the Copilot harness is not connected, then switch #2
must be set to the “ON” position. With the wire connected the options below are available.
If you want automatic OD cancel from a stop flip #2 switch ON
If you do not want automatic OD cancel from a stop flip #2 switch OFF
----------------------------------------------------------------------------------------------------------------------------------------
Switch #3
Speed setting
On=low speed cut out (deceleration only) This setting is designed to be used with an exhaust brake.
Off=Hi speed cut out (deceleration only)
----------------------------------------------------------------------------------------------------------------------------------------
Switch #4
S
et this switch to the ON position
---------------------------------------------------------------------------------------------------------------------------------------
We have preset the Co-Pilot module #1-ON, #2-ON, #3-OFF, #4-ON
