3 Detailed Information
Details of functions
The aD5 has many other functions.
For detailed information and a detailed explanation of the functions, refer to the “Reference Guide”
PDF.
You can download the “Reference Guide” PDF from the following URL.
http://products.atvcorporation.com/drums/ad5/
Specications
Electronic Drum Sound Module
Model: aD5
Item Specications
Connection jacks /
Interfaces
OUTPUT L/R: mono phone x 2
PHONES: stereo phone
AUDIO IN: stereo mini-phone
MULTI TRIGGER INPUT: dedicated multi-connector
AUX TRIGGER INPUT 1/2: TRS phone
USB: 2.0 type B connector (High Speed)
ATV LINK: RJ45 LAN connector
SD CARD: SD/SDHC card
DC IN: only for the included AC adapter
Power supply DC 12 V
Current
consumption
600 mA
Dimensions
197 (W) x 144 (D) x 73 (H) mm
7.8 (W) x 5.7 (D) x 2.9 (H) inches
Weight 1.1 kg
* Specications and appearance of this product are subject to change without notice for improvement.
Support
• Refer to the following URL for frequently asked questions, rmware updates, and other
information.
http://products.atvcorporation.com/drums/ad5/
