TH106, TL6160 PROGRAMMABLE THERMOSTAT
69-2202—07 4
8. Power Outage
During a power outage, LP (Low Power) appears for the first
minute. Then the screen becomes blank. The settings are
stored in memory. After initial installation, product must be
connected to power for a minimum of two hours to enable
the power outage feature. However, if the power failure
exceeds 4 hours, the thermostat’s clock must be re-adjusted
and, if you are using the automatic Daylight Savings Time
changeover function, it must be re-enabled. When power
returns, the thermostat will return to the mode of operation
active prior to the power failure.
9. Troubleshooting
10. Technical Specifications
Power:
120/240 VAC, 60 Hz
Minimum load:
2 A (resistive only)
250 W @ 120 VAC
500 W @ 240 VAC
Maximum load:
16.7 A (resistive only)
2000 W @ 120 VAC
4000 W @ 240 VAC
Display range:
32°F to 140°F (0°C to 60°C)
Display resolution:
1°F (0.5°C)
Setpoint range:
40°F to 86°F (5°C to 30°C)
Setpoint interval:
1°F (0.5°C)
Storage:
-4°F to 120°F (-20°C to 50°C)
Approval:
c UL us
ICES-003 Class B Notice
This Class B digital apparatus complies with
Canadian ICES-003.
Problem Solutions
Thermostat is hot. Under normal operation, the
thermostat housing can reach a
temperature between 95°F (35°C) and
104°F (40°C).
LO is displayed. The measured temperature is below
the display range. Heating is activated.
HI is displayed. The measured temperature is above
the display range.
Wrong temperature
is displayed.
The thermostat is exposed to air draft.
Eliminate the draft. The sticker on the
thermostat’s screen has not been
removed.
Wrong time is
displayed.
The thermostat was without power for
more than 4 hours.
Temperature does
not change
according to the
programmed
schedule.
Check that the thermostat is in
Automatic mode. Check the schedule
and clock settings.
LP appears on the
screen or the screen
is blank despite
there is no power
outage.
The thermal circuit breaker in the
heater is opened. This can happen if
the heater is obstructed by furniture or
curtain and has overheated, or if the
thermal circuit breaker is defective.
Display looks faded
when heating is
activated
The heating system is less than the
required minimum load. This
thermostat cannot be used below that
rating.
The settings cannot
be changed.
The settings are locked (see section
3).
E2 is displayed The thermostat performance is
reduced due to a sensor error. Please
contact technical support for more
information.
273699
