Chapter 3
Connecting the Amplifier
NOTE
MakesurethepowerisswichedOFFwhenanychangeismadetotheconnectionsofthe
amplifier.
Input connections
TheinputconnectionsoftheamplifierareperformedusingbalancedXLRconnectors.Every
channelhasaXLRinputconnectorandaXLRlinkoutputconnector.
Theinputsignalfromthesignalsource,pre-amplifierormixershouldbeconnectedtothe
XLRinputconnections.AndbymeansoftheXLRlinkoutputconnectors,thesignalcanbe
linkedthroughtomultipleamplifiers.
AC Input
230V 50Hz, 1080W
FU SE T6.3AH /250V
CAP424
AUDAC
Output connections
Theloudspeakeroutputconnectionsareperformedusing4-pinterminalblock
connectors,makingitpossibletoconnecthighimpedance(100V)loudspeakerstothe
amplifieroutputs.
