Chapter 1
Pin connections and connectors
CONNECTION STANDARDS
Thein-andoutputconnectionsforAUDACaudioequipmentareperformedcorresponding
tointernationalwiringstandardsforprofessionalaudioequipment.
Cinch (RCA):
Forunbalancedlineinputconnections
 Tip: Signal  Sleeve:  Ground
 White: Left  Red: Right
XLR:
Forbalancedsignalinputconnections
 Pin 1: Ground
 Pin 2: Signal+
 Pin 3: Signal-
Forbalancedsignallink-throughconnections
 Pin 1: Ground
 Pin 2: Signal+
 Pin 3: Signal-

Wire up the system
Thewiringofthesystemmustbedoneaccordingtothefollowingrules,toguaranteea
properfunctioningofthesysteminallcircumstances.
1. Speakercableforamplifiedoutputs:
  Minimum 2 x 1.5 mm²
If distance > 15m: 2 x 2.5 mm²)

2. Musicsourcesandzoneoutputs:
Must be connected with high-quality audio cable and high-quality
connectors
