Introduction

Multi Channel 100V Power Amplifiers

TheCAPSeriesareprofessional100VMulti-ChannelPowerAmplifiers,containingvarious

modelswithdifferentchannelsanddifferentoutputpowerconfiguration.Differentoutput

configurationswithtwoandfourchannelsandpowerratingsfor120Watt,240Wattand

480Wattforeachchannelareavailable.

Thisway,aflexiblesolutioniscreatedforMulti-Zoneaudiodistributionsystemswithtwo

ormoreindependentzones.

Theyaredesignedasno-nonsenseamplifierswithonlythenecessarycontrolsand

connections,whichcreatesgreatsimplicityinuseandinstallation.Ahighefficiencyand

reliabilityofthedevicesisachievedbyusingswitchingpowersuppliesincombinationwith

Class-DAmplifiertechnology.Atemperaturecontrolledfanconstantlykeepsallpartswithin

therightoperationrange,whileavoidingexcessivebuzz.Abuilt-inmultipurposeprotection

circuitprotectsagainstDCmalfunction,Shortcircuit,overheating,overloadandlimitsthe

signalwhennecessary.

TheinputconnectionsareperformedusingbalancedXLRconnectorsandLinkoutput

connectorsareprovidedforlinkthroughtootheramplifiers.Besides,ahigh-passfilter

switch(400Hz)andaGainadjustmentpotentiometerareprovidedforeachchannel.

Theoutputconnectionsareperformedusingreliableterminalblockconnectorsandthisall

ishousedintoasolidconstructed,doublerackspace(2HE)19”rackmountinghousing.

AUDAC CAP224 User Manual
