Additional Information COM12/COM24
Technical specifications
COM12 COM24
Sensitivity
Balanced Microphone Channels -50dB±3dB
Balanced Line Channels -22dB±3dB
Balanced Remote Microphone station -50dB±3dB
Balanced Telephone Paging -21dB±3dB
Unbalanced Link In -17dB±3dB
Unbalanced Amp In -0dB±3dB
Frequency Response (1Watt from speaker output
tap. 100Hz-10kHz)
+1.5dB / -3dB
THD+N by 1 kHz Less than 0.5%
Signal to Noise ratio 90 dB@1kHz
Phantom Power +15V DC
Zone outputs 1-5 100V
Output level & impedance 100V – 83 ohm
70V – 42 ohm
25V – 5,2 ohm
4 ohm – 22V
100V – 42 ohm
70V – 21 ohm
25V – 2,6 ohm
4 ohm – 31V
Power Supply 235V AC, 50-60Hz
Max. power consumption 170W 260W
Weight 9.76 kg 8,5 kg
Dimensions (W x H x D) 420 mm x 88mm x 320mm
Unit height 2HE
