AUDAC COM12 - Overview Input Controls (same for the Com24); Input 1 - 6 (Front); Overview Output Controls (same for the Com24); Output 1-5 ( Front )

8
88
8
Overview Input Controls (same for the COM24)
INPUT 1 - 6 (FRONT)
Overview Output Controls
(same for the COM24)
OUTPUT 1-5 ( FRONT )
Output
clipping
LED
2 band tone control
Chime button
Zone output routing buttons
Power button and
blue
ON
-
led
Input volume controls
Output VU
-
bar
Master volume
control
