Pin connections on Connectors
Cinch (RCA)
:
tip = signal (left or right)
ring = ground
XLR:
1 = ground / shield
2 = +sig
3 = -sig
XLR female:
XLR male:
6.3mm (1/4”) balanced jack plug:
tip = +sig
ring = -sig
sleeve = ground / shield
6.3mm (1/4”) unbalanced jack plug:
tip = signal
sleeve = ground / shield
