Chapter 1
Connections and connectors
CONNECTION STANDARDS
The in- and output connections for AUDAC audio equipment are performed according to international wiring
standards for professional audio equipment
1. 3.5 mm Jack (AUX):
For unbalanced line input connections
2. RCA (COAXIAL):
For coaxial SP/DIF digital input connections
3. TOSLINK (OPTICAL)
For optical SP/DIF digital input connections
3. HDMI ARC:
For HDMI (ARC) input connections
USB
USB-a: For playbacks and updates
Tip:
Ring:
Sleeve:
Tip:
Sleeve:
HDMI Type A (19-pin)
Pinout:
Left
Right
Ground
Signal
Ground
According HDMI specications
