Parking sy stem s
CD Note
Keep enough distance from the curb to avoid
damage to the rims .
@ Tips
The left or right orientation lines and surfaces
will be displayed, depending on the turn sig-
nal being used .
Peripheral cameras
Introduction
Applies to vehicles: with peripheral cameras
With this equipment, die parking system plus* is
supp lemented with var ious peripheral cameras
qpage 114. Depend ing on vehicle equipment,
you are provided with the following views:
Around the vehicle, front corner and rear corner,
in front of the vehicle and behind the vehicle.
General information
Applies to veh icles: with peripheral cameras
Fig. 130 Location of periphe ral cameras
Depending on the vehicle eq uipment, the periph -
eral cameras are fou nd in the radiator grille, in
the luggage compa rtment lid and on both exteri -
or mirrors *
q fig. 130. Make sure that the lenses
are not covered by deposits or any other obstruc-
tions as it may impair the system. For informa-
tion on cleaning, refer to¢
page 203.
In the Surround ing mode, black corners are
shown in the vehicle silhouette. Objects in these
areas are outside of the camera's field of view
and are not detected.
118
The accuracy of the orientation lines and the blue
surfaces is reduced if the adaptive air suspen-
s ion* is fau lty, if the veh icle is lifted or if the
Dy-
nam ic mode is activated q page 100.
A WARNING
- Always read and follow the applicab le warn-
ings¢ .&
in General information on
page 113.
- If the position or the installat ion angle of a
camera was changed, after a collis ion for ex-
ample, do not continue to use the system
for safety reasons. Have it chec ked by your
authorized Audi dealer or authori zed Audi
Serv ice Facility.
- Keep in mind that the image in the display is
distorted if the exter ior mir ror ho using has
been manually adjusted.
- Use the
Rear mode and the corner view
(rear)
mode only when the luggage com-
partment lid is fu lly closed. Otherwise the
image in the disp lay will be disto rted.
- The vehicle surroundi ngs are shown using
the camera images. The veh icle image is
shown by the system. Objects and obstacles
above the camera are not displayed.
- Camera lenses enlarge and distort the field
of vision. The objects appear both a ltered
and inaccurate on the screen.
CD Note
- Always read and fo llow the applicable warn-
ings
¢ (Din General information on
page 113 .
- The Infotainment d isp lay shows the direc -
tion in which the rear of the vehicle is travel-
ing based on the steering wheel ang le. The
front of the vehicle front sw ings out more
than the rear of the vehicle. Maintain plenty
of distance so that your outside mirror or a
corner of your vehicle does not collide with
any obstacles.
(I} Tips
If the 8/(J;(SJ/c:, symbol appears in the dis-
play and the respective display area is grayed
out, then the power exter ior mir rors we re
fo lded in or the dr iver's door/front
